NNC68B
CLION
| Availability: | |
|---|---|
| Quantity: | |
The NNC68B Series introduces a compact yet highly efficient miniature relay known for its impressive performance despite its small size. These miniature intermediate power relays exemplify core electromagnetic principles by utilizing a coil, contacts, and multiple contact points to manage current flow within a circuit. The operational principle is straightforward: when current flows through the relay’s coil, it creates a magnetic field that engages the contacts, closing the contact points and allowing current to pass through. This functionality makes it a reliable electromagnetic relay switch.
Exceptional Power Handling: The NNC68B Series delivers high power capabilities, with a switching capacity reaching up to 10A. This makes it ideal for demanding electrical systems such as industrial machinery, automation setups, and other high-power applications. Whether you need a miniature power relay for robust use or miniature intermediate power relays for specialized tasks, this series performs exceptionally.
Secure PCB Connections: Equipped with PCB terminals, these relays provide secure and stable connections, facilitating straightforward integration into printed circuit boards. This ensures dependable connectivity, making the NNC68B Series a reliable choice for engineers looking for high-quality miniature relays.
Versatile Applications: The NNC68B Series is versatile enough for general-purpose use. It is suitable for controlling everything from industrial equipment and HVAC systems to lighting setups and consumer electronics. Its adaptability as a miniature general purpose relay ensures it can handle a variety of applications with ease.
Long-Lasting Durability: Renowned for its durability, the NNC68B Series promises reliable operation over an extended period. This minimizes the frequency of replacements, helping to cut down on maintenance expenses. Its robust design makes it a cost-effective choice for projects that require a miniature power relay with long-lasting reliability.
Energy Efficiency: Featuring low power consumption, this relay enhances overall energy efficiency. Its economical design leads to significant cost savings over time, making it an ideal option for applications that demand extended use.
The NNC68B Series offers a range of configurations to suit various needs:
Contact Poles: Available in 2 to 4 poles, these options provide flexibility in circuit design, making it easy to integrate into different systems.
Contact Forms: Includes configurations such as 2Z (DPDT), 3Z (TPDT), 4Z (4PDT), 2H (DPST-NO), 3H (TPST-NO), 4H (4PST-NO), and 2D (DPST-NC). These forms cater to different switching requirements and are perfect for diverse uses of miniature relays.
Rated Contact Load: Ranges from 5A for configurations with 4 poles to 10A for those with 2 poles, ensuring reliable switching for various current needs.
Coil Voltage Compatibility: Supports a broad spectrum of voltages, from DC 3V to 110V and AC 6V to 240V, offering versatility for different electrical setups.
Environmental and Mechanical Properties
Insulation Resistance: Maintains a minimum of 100MΩ, ensuring safety and reliable operation.
Dielectric Strength: Rated for both coil-to-contact and between open contacts of the same pole, suitable for various conditions.
Shock and Vibration Resistance: Withstands significant shock and vibration, making it ideal for harsh environments.
Operating Temperature Range: Operates effectively from -40°C to 85°C, suitable for diverse climatic conditions.
Conclusion
The NNC68B miniature intermediate power relay stands out as a high-performance component designed for a wide range of applications. It combines excellent power handling, versatile configurations, secure PCB connections, and a broad range of uses, making it the optimal choice for engineers seeking reliable and effective miniature relay solutions. With features like the lockable test button and durable construction, the NNC68B ensures superior performance and smooth operation in your electronic systems.
